Workstations for ArcGIS Pro

What is the best CPU for ArcGIS Pro?

ArcGIS Pro is able to utilize a moderate number of CPU cores – Esri lists a minimum of 2, with 4-10 being recommended – and of course clock speed is also a major factor in performance. That makes a processor like Intel’s Core i9 13900K a fantastic choice. It has 8 “performance” cores that offer some of the highest per-core clock speeds available, along with another 16 “efficiency” cores which are slower but ideal for multitasking and handling background threads. The newer i9 14900K is also great, but only a percent or two faster and unfortunately not available in our most compact workstations

What is the best type of video card (GPU) for ArcGIS Pro?

Basic visualization of project data in ArcGIS Pro doesn’t require a particularly powerful video card – anything with mid-range 3D performance and at least 4GB of onboard memory should do the trick. However, Esri has added support for general-purpose computing on select GPUs to enable features like deep learning and spatial analysis.

If you want to take advantage of that functionality then you need a CUDA-capable graphics card from NVIDIA with a much higher amount of VRAM. The GeForce RTX 40 Series cards are a solid option here, and our ArcGIS Pro workstation can handle models like the GeForce RTX 4070 SUPER 12GB and RTX 4080 16GB. If you have a unique use case that needs even more graphics memory, NVIDIA’s professional RTX A-series cards go as high as 48GB!

How much memory (RAM) does ArcGIS Pro need?

Esri recommends 32GB, so that is the minimum we offer on our ArcGIS Pro workstations. For large projects, or if you run a lot of other software at the same time, 64GB may be optimal. That is where our standard ArcGIS Pro system maxes out, but we have other configurations available which support even more memory if you think your workload requires it.

What is the best type of drive to use for ArcGIS?

A solid-state drive (SSD) is essential for good performance in any application, and for the best experience we recommend a high-speed NVMe model. A mid-size drive should be plenty for your operating system along with ArcGIS Pro and whatever other software you use, and then our recommendation is to have a second SSD – which doesn’t need to be as fast – for storing your projects and other data files. This way your data isn’t directly impacted if you ever need to reinstall the OS, and in a pinch you could remove the storage drive and move it to another system if that was ever necessary.

What sort of drive is best for data storage and backup?

Since SSDs are still more expensive than platter drives per GB, for long term storage and backup we recommend using a traditional hard drive or even an external drive array. Network attached storage systems are a great way to go for that, as they can be shared between multiple workstations and usually offer features to provide some level of data redundancy (protection against losing files if one of the drives dies).
